### Crossing Over

When hobbies complement each other

I've been working on my (model) railroad, and the equipment that I've collected over the past 30 years has become difficult to manage. I have cars in boxes in a closet, in the attic, and even in a display case in my office. Most of the cars are in the original boxes they were purchased in, and after many years, they are becoming brittle. Another challenge that most model railroaders face is that the box is just big enough to hold the car kit. Once you add details, couplers, and assemble it, it becomes the proverbial 10 pounds of stuff in a 5 pound bag.

Since I enjoy woodworking and have a fairly well-equipped shop, I decided to make a cabinet to store everything. I started by measuring the standard height of the cars, and the most common lengths. Using a spreadsheet, I was able to calculate the optimal size of the drawers with cabinets ranging in width from 36 to 40.5 inches wide. This also allowed me to determine, based on the number of each size of car, how many rows of storage would be needed. I could fit six of the standard scale 40 foot cars in one row in the drawer, and in a 22-inch depth could fit 11 rows, or 66 cars.

The final size is an overall height of 34 inches, a depth of 23.5 inches, and a width of 40.5 inches. This will fit well under the model railroad with room to spare. I'll likely add castors to raise the cabinet off the floor and allow it to be moved for wiring or maintenance under the layout. So the detail would be clear, the drawer face is semi-transparent.

Well, with all of the calculations complete, I set about creating some drawings. I use InkScape - a free drawing tool. My only complaint is that it doesn't have auto-dimensioning like Corel Draw and most CAD software, but it works well for me. I drew the plans in outline form, but for presentation here, filled the objects.

#### Drawings

Below are the front and side views. I'm waiting for delivery of a sheet of half-inch ply for the drawer boxes. I just built a couple of box-joint jigs for the router table and this will be the perfect opportunity to put them to use. Once construction starts, I'll post some photos.

The drawings show 10 drawers, with the top-most drawer face being 5/8" taller to handle a few of the taller cars, like the domed passenger cars. These could fit into a normal height drawer if I added some felt lining and laid them on their sides. 10 drawers might actually be quite a bit more than I need, but I can remove 2 drawers and roughly double the drawer face height and use them for storing other structure kits. The design is quite flexible. The images show a typical 40-foot freight car illustrating the placement of 6 cars per row in the front view and 11 rows of cars in the side view.
